Cabinet Plumbing Jig

Quickly and easily transfer the location of existing pipes and electrical outlets to the back of cabinets for easy drilling.

AWFS 2023 Visionary award winner

Cabinet Plumbing Jig

Cabinet Plumbing Jig

Quickly and easily transfer the location of existing pipes and electrical outlets to the back of cabinets for easy drilling.

AWFS 2023 Visionary award winner

CABINET PLUMBING JIG

$299

Cabinet Plumbing Jig

$299

FREE Shipping
Money Back Guarantee
What's Included
Specifications
Instructions

Cabinet Plumbing Made Easy

HOW IT WORKS

The True Position Tools Cabinet Plumbing Jig helps you quickly and easily transfer the location of existing pipes and electrical outlets to the back of cabinets for easy drilling. Just align, lock, and transfer.

Adjust arms to plumbing

Transfer to cabinet and mark

Drill plumbing holes

Install cabinet

Accurate Hole Spacing

Wall

The Gap Wire ensures that you will have adequate spacing around your pipe.

Cabinet

The Gap Wire is pre-set to 1/4” to ensure that your drilled hole will be about 1/2” larger in diameter than your pipe.

Electrical Outlets

Adjust Swivel Head to outlet

Transfer to cabinet and mark

Cut outlet hole

Install cabinet

Install with Confidence

Install sink cabinets 3x faster with the True Position Tools Cabinet Plumbing Jig. First, adjust the jig arms to meet your pipe, drain, or electrical outlet location. Next, secure the jig arms in place and transfer the jig template to the back of your kitchen or bathroom vanity cabinet. Lastly, mark the plumbing and electrical locations mapped by the jig and drill. Our patented design eliminates the complex math and measurements traditionally needed during sink cabinet installation. And, results are cleaner and more accurate than traditional installation methods.

FAQs

Rather than measure the size of the pipe, measure the size of the valve and add ½” clearance to determine the hole saw size you’ll need. The Cabinet Plumbing Jig set includes a Valve Sleeve to place over a pre-existing valve for easy placement. Just slide the Valve Sleeve over the pipe and lower the jig Arm until the Gap Wire touches the Valve Sleeve. Use a 2 ⅛” hole saw to ensure that the hole is large enough to accommodate the valve. If using a larger hole saw, adjust Gap Wire accordingly.

Increase the size of the hole saw to ensure that the hole will fit the angled pipes.

If you have a vanity cabinet less than 30 inches in length, use the Center of the jig (not the edge stop) to determine your pipe locations.

30″ x 31″ x 2″  (W x L x H)

Yes, the Cabinet Plumbing Jig comes with a sturdy, soft-shell case that fits all kit materials.
